• 2171XXXE Box Header Pitch:2.54mm With Ejector Header Straight / Right Angle Type RoHS

    2171XXXE Box Header Pitch:2.54mm With Ejector Header Straight / Right Angle Type RoHS

    Specifications

    • Insulator: PBT Polyester UL 94-V0
    • Color: Black
    • Contacts : SQ 0.64mm Gold / Tin Seletive Plated
    • Current Rating: 1.5 Amps
    • Operation Temperature: -25℃ ~ +85℃
    • Contact Resistance: 10 m ohms max
    • Insulation Resistance: 1000 MΩ min
    • Dielectric Withstanding: 500V AC

    2171-001
